OCL: |
350uH Min. @100KHz/0.1V with 8mA DC Bias |
|||||
|
Hi-POT : |
1500VAC |
|||||
|
Turn Ratio: |
1:1±3% |
|||||
|
LK: |
0.5uH Max @100KHz/0.2V |
|||||
|
Cw/w |
28PF Max @100KHz/0.2V |
|||||
|
D.C.R: |
1.2 ohm Max |
|||||
|
Insertion Loss: |
1-100MHz: -1.0dB Max |
|||||
|
Cross Talk : |
30MHz |
60MHz |
100MHz |
|||
|
-45dB Min |
-38dB Min |
-33dB Min |
||||
|
Return Loss: |
1-30MHz |
40-50MHz |
60-80MHz |
100MHZ |
||
|
-16dB Min |
-13dB Min |
-11dB Min |
-10dB Min |
|||
|
D.C.M.R: |
30MHz |
60MHz |
100MHz |
|||
|
-43dB Min |
-37dB Min |
-33dB Min |
||||
